SF6 Precision Dew Point Meter (Winfoss-P1)
SF6 precision dew point meter
Supported platform: Windows/Linux/Unlix
Software size: 10M
Brand: WINFOSS
Model: Winfoss-P1
Dew point measurement: -80-- +20°C, accuracy ±0.2°C.
Response time: (+20℃) -60 → +20°C 5s (63%) 45s (90%) -20 → +60°C 10s (63%), 240s (90%).
Working pressure: 0-1Mpa.
Printing: Built-in micro printer can print test data in real time.
Storage function: data storage function, easy for users to query later.
产品详情/ Product details
The SF6 Precision Dew Point Meter (Winfoss-P1) uses a sensor from VAISALA of Finland, which uses DRYCAP film sensing technology, a composite film humidity sensitive material, and holds three world patents: the Mylar type probe DRYCAP, which is resistant to condensation, dust particles, and is not affected by gasoline and most gases. The instrument has an automatic calibration function. In on-line measurement, the automatic calibration software automatically corrects the drift of the dry end of the measurement curve, and maintains the stability of the wet end through periodic self-recovery to ensure that the measurement curve is consistent with the theoretical curve.
SF6 Precision Dew Point Meter (Winfoss-P1)
Finland VAISALA sensor, DRYCAP film sensing technology; Good repeatability, fast response, simple operation, easy to carry!
summarize
The SF6 Precision Dew Point meter (Winfoss-P1) uses a sensor from VAISALA of Finland, which uses DRYCAP film sensing technology, composite film humidity sensitive material, mylar type probe DRYCAP, which is resistant to condensation, dust particles, and is not affected by gasoline and most gases. The instrument has an automatic calibration function. In on-line measurement, the automatic calibration software automatically corrects the drift of the dry end of the measurement curve, and maintains the stability of the wet end through periodic self-recovery to ensure that the measurement curve is consistent with the theoretical curve.
In addition, the probe is automatically heated. This function is used to automatically calibrate anti-condensation (10 degrees above ambient temperature), anti-oil (heated to +300 ° C, for instant evaporation of various oil polymerized on the probe surface). The DMT242 is designed for extremely harsh environments and is resistant to pollution, water and dust.
Functional characteristics
l Lithium battery power, a charge can be used for 5-8 hours.
l Charging module adopts automatic management mode, automatic charging and automatic shutdown.
l Built-in micro printer can print test data in real time.
l Data storage function, easy for users to query later.
l Measurement accuracy (± 0.05Mpa) and resolution (0.01Mpa) high, fast response speed.
Technical index
Serial number | ginseng The number item Orders, | ginseng The number value |
one | Dew point measurement | -80-- +20° C, precision ± 0.2 & deg; C |
2 | exportation | 4--20mA |
3 | communication | RS-232 |
4 | Response time | (+ 20° C) -60 → +20° C 5s (63%) 45s (90%) -20 → +60° C 10s (63%),240s (90%) |
5 | Use environment | Temperature:0 ~+60° C Humidity:0-100%RH |
6 | Working pressure | 0-1Mpa |
7 | Flow control | 0-1 L /min |
8 | Power source | Ac, DC dual purpose, rechargeable |
9 | volume | 300*230*100mm |
10 | weight | 2．5kg |
disposition
l SF6 precision dew point meter 1 set
l 1 test pipe with needle valve
l 1 air outlet pipe
l One power cable
l Aluminum alloy shockproof box 1
l 1 Chinese manual
l Factory inspection report and other user data 1 copy
l 1 dew point sensor detection report
l 3 connectors (DILO 1, Taikai 1, Xikai 1)
Service guarantee
l Provide on-site training guidance and carry out on-site demonstration operation.
l Provide detailed instructions and user guidance in Chinese.
l One year free warranty, lifelong spare parts support and maintenance.
l Hotline 365 days to answer the user's consultation.
